Rotary Type Plastic Shoes Automatic Injection Moulding Machine NSK-286
Rotary Type Plastic Shoes Automatic Injection Moulding Machine NSK-286
Taichung City, Taiwan
orCall 886-4-2533-1108
Specifications
| Condition | New |
| Screw rod diameter | Ø70 mm |
| Ejective capacity | 600 cm³/shot |
| Screw revolution | 0-100 r.p.m. |
| Motor of spiral oil pressure | 275 kg-m |
| Motor of oil-pressure pump | 6P x25HP kw/pole |
| Mould clamping force | 50 ton |
| Mould clamping space(max.) | 245 mm |
| Size of mould available (max.) | 240 x 400 mm |
| Mould clamping frame | 20 STATION |
| Electric heating capacity(glue) | 8 kw |
| Acting oil capacity | 550 L |
| Machine size | 3700 x 2500 x 1800 mm |
| Machine weight | 6.4 ton |
| Gross weight | 6.9 ton |
| Packing dimension | 4000 x 2040 x 2200 mm |
