Two Color Rotary Type Plastic Shoes Automatic Injection Moulding Machine NSK-286-2C

Two Color Rotary Type Plastic Shoes Automatic Injection Moulding Machine NSK-286-2C
Location:Taichung City, Taiwan
Description
NSK-286-2C is controlled by P.L.C. accurately; smoothly and easy maintenance. Independent hydraulic system; precise pressure & high production capacity & top quality products. Unique design in clamping cylinder make strong clamping force product without burr. Firmed steel close-mould seat,It will never be deformed. Steady disc control by hydraulic transition system,It will make the disc turn faster, set it accurately and without noise. Clamping cylinder, Speedy high production & not damage the mould. Screw rotation with hydraulic motor, Feeding smooth;speedy & soundless. The machine specializes for making two colors, foaming or unfoaming products. It can also make one color products independently. Even a skilless worker can operate & maintain this machine easily. Auto feeding system control by computer: Feed the material precisely & easy to adjust. Auto computer scout system for disc's rotation : Locate accurately & without displacement.
Specifications
Condition | New |
Screw rod diameter | Ø70x2 mm |
Ejective capacity | 600x2 cm³/shot |
Screw revolution | 0-100 r.p.m. |
Motor of spiral oil pressure | 275 kg-m |
Motor of oil-pressure pump | 4Px3HPx2,6Px25HPx2 kw/pole |
Mould clamping force | 50 ton |
Mould clamping space(max.) | 240 mm |
Size of mould available (max.) | 370 x 520 mm |
Mould clamping frame | 20 STATION |
Electric heating capacity(glue) | 16 kw |
Acting oil capacity | 550 x2 L |
Machine size | 6300 x 6100 x 2100 6300 x 6500 x 2000 mm |
Machine weight | 9.8+7.3 ton |
Gross weight | 10.3+7.8 ton |
Packing dimension | 5600x1600x2150 3800x1300x2000 mm |
Hydraulin injection system | injects quantity accurately & high capacity. |
Special design for feeding screw | Cause to a large quantity of production. |
